NT-8040R NVR Titan Standalone Ampliar

NT-8040R NVR Titan Standalone

NUUO NT-8040R Titan Standalone NVR (4-Canales, 8-bahías)

Más detalles

NT-8040R


Indicarme cuando esté disponible
  • 250 Mbps
  • Cable de Poder 2U para montaje en rack / US
  • Linux embebido
  • Motor de grabación F.R. Mega optimizado
  • RAID 0, 1, 5, 1 0
  • Cadena de Comando / doble Gigaports
  • centralizada Respond E-Map / Evento
  • 400 CH (Live), 100 CH (Reproducción)
  • Compatible con iPhone / iPad / Android



Part NumberServerNT- 8040R
IP LicenseNT-TITAN-UP-01 / NT-TITAN-UP-04 / NT-TITAN-UP-08 / NT-TITAN-UP-12 / NT-TITAN-UP-16
CPU ModelIntel® Core™ i5-2400 Processor (6M Cache, up to 3.40 GHz)
Max IP License(through upgrade)64
Base IP License (included in server)4
Server O/SEmbedded Linux
Video CompressionH.264, MPEG4, MJPEG
Recording Performance250 Mbps
Removable HDD Trays8x SATA II
HDD Support3TB per drive (Max 8 drives)
RAID0, 1, 5, 10
External StorageDAS, iSCSI ( Http://support.nuuo.com for details )
External Ports2 x USB3.0, 2 x USB2.0, 1 x eSATA (for DAS)
Ethernet (NIC)2x Gigabits Ports
Voltage100-240V
Power ConsumptionFull loading: 155W, Max: 400W
Dimension (HxWxD)88 x482 x 583 mm
Weight (without HDD)10.6 kg (23.37lbs)
Temperature0°C ~ 40°C (32°F ~ 104°F)
Humidity5% ~ 95%
Supported Language (21  languages)Chinese (Simplified), Chinese (Traditional), Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Serbian, Slovenian, Spanish, Swedish, Thai, Turkish
LiveView spot-out
(Local display)
16CH local display in D1, 30 FPS
*Max recording throughput (250 Mbps): Approx. 64ch 5-Megapixel H.264 cameras at 10 fps when server is streaming out 16 channels of live video without playback.
*Optimal recording throughput (150 Mbps): Approx. 64ch 2-Megapixel H.264 cameras at 15 fps when server is streaming out 128 channels of live video and 16 channel playback.
