QNAP QVP-41C
NVR de alto rendimiento de 4 bahías para Pymes, usuarios domésticos y oficinas pequeñas
NVR PoE de 4 canales, 1 bahía.
Video Input |
|
IP Camera Input |
4 Channel |
Incoming Bandwidth |
40 Mbps |
Outgoing Bandwidth |
40 Mbps |
Video Output |
|
HDMI Output |
3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768 |
VGA Output |
1920 × 1080, 1280 × 1024, 1024 × 768 |
Decoding Capacity |
1ch 12MP, 4ch 4MP |
Dual Stream |
Support |
Multi-screen Display |
1/4 |
AI Recognition |
|
Face Comparison |
Real-time captured and display faces comparison results (registrant (name and ID), stranger, channel, similarity) |
Multi-objective |
Real-time captured and display vehicle, human body, non-motor vehicle, license plates image, and faces comparison results (registrant, stranger, channel, similarity) |
Smart Search |
Time, Properties, Pictures, License plate |
Trigger Events |
Buzzer, Alarm push, Alarm prompt, Email, Alarm Out, Compare the result simultaneously, etc. |
Recording |
|
Resolution |
12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
Recording Mode |
Manual, Schedule (Regular, Continuous), Event |
Trigger Events |
Motion Detection, Video Loss, Alarm in, IVS |
Playback and Backup |
|
Sync Playback |
4/1 |
Search Mode |
Time /Date, Alarm, Picture grid, Event |
Backup Mode |
USB Device, Network |
Alarm |
|
General Alarm |
Motion Detection, Video Loss, Alarm in, Alarm out |
Intelligent Analysis (By Camera) |
Smoking Detection, Smoke and Fire Detection, Fire Spot Detection, Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-way, Illegal Parking, People Counting, Smart motion detection, Enter Area, Leave Area, etc. |
Abnormal Alarm |
Disk Alarm, IP Address Conflict, Network Disconnect |
Intrusion Detection (By NVR) |
4-ch, support the accurate detection of human and vehicle |
Network |
|
Network Function |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE |
Remote Users |
8 users |
P2P |
Support |
Interoperability |
ONVIF, SDK, CGI |
ANR |
Support |
Interface |
|
HDD Interface |
1 SATA interfaces, up to 12TB capacity for each disk |
Network Interface |
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port |
PoE Interface |
4 ports, 10/100Mbps, 802.3af, max 32W |
HDMI |
1 |
VGA |
1 |
Audio In/Out |
1/1 |
Alarm In/Out |
4/1 |
USB Interface |
Front panel: 2 × USB 2.0, Rear panel: 1 × USB 2.0 |
Reset Button |
On-board reset button |
General |
|
Power Supply |
48VDC/1.25A |
Power Consumption |
< 15 W (without HDD) |
Operating Conditions |
-10 °C to 50 °C (14 °F to 122 °F) |
Storage Conditions |
Less than 90% RH |
Certifications |
CE/FCC |
Dimensions |
255 × 235.1 × 47.5 mm (10.04 × 9.26 × 1.87 inch) |
Net Weight |
0.9 kg (1.98 lb) without HDD |
